A buckling-restrained brace frames into a steel beam at a floor level via a slotted gusset plate welded to the steel beam, with the gusset and attachment design delegated to the manufacturer. One-half-inch thick stiffener plates are welded to both the near side and far side of the gusset plate with five-sixteenth-inch fillet welds. Additional plate elements connect at the beam centerline work point, while concrete over steel deck bears against the assembly.
Wb Lwb Wb Lwb TYP GUSSET THICKNESS, tg 5/16 5/16 TYP STIFF PL 1/2" NS & FS OF GUSSET COREBRACE BRB TYP STL BM SEE PLAN WORK POINT AT 1/2" NOMINAL DEPTH OF BM Lgb Lgc PL 1/2" NS & FS WORK POINT COREBRACE BRB TYP 5/16 5/16 TYP GUSSET AND ATTACHMENT DESIGN BY COREBRACE TYP SLOT GUSSET TO RECEIVE BRB TYP CONC OVER STL DECK STL BM SEE PLAN STIFF PL 1/2" NS & FS OF GUSSET Wb Lwb Wb Lwb Lgb Lgc
