A drift track profile matches the stud depth and accommodates two inches of in-plane wall drift in either direction beneath the support structure. Two powder-actuated fasteners per sixteen inches on center with a three-inch gauge secure the track to the support structure. A three-quarter-inch deflection gap is maintained at the head of the wall. Bridging option one or three is required at this location twelve inches maximum from the connection.
(2) PAF @ 16" OC MAX, 3" GAGE, FOR TRACK TO SUPPORT STRUCTURE 3/4" DEFLECTION GAP DRIFTTRACK DTSLX00-68, MATCH STUD DEPTH, ACCOMMODATE 2" DRIFT IN-PLANE OF WALL IN EITHER DIRECTION BRIDGING OPTION "1" OR "3" REQD AT THIS LOCATION 12" MAX 12" MAX
