A bent u-shaped closure plate supports a concrete infill slab with a thickness matching the adjacent slab "t". Two continuous number 4 reinforcing bars run longitudinally through the concrete. The closure plate is welded to the supporting steel beam with a one-half inch fillet weld spaced at twenty-four inches on center, while plate thickness and overhang dimensions are sized per plan and referenced to the typical slab closure detail.
