A horizontal hollow structural section tube member frames into the face of a vertical hollow structural section column with welded joints. A five-sixteenth inch typical fillet weld connects the sides of the intersecting tube, while a one-quarter inch typical fillet weld with a one-eighth inch root opening is specified at the top and bottom. A note indicates that detail 11/S536 may be used in lieu of this connection at the fabricator's option.
5/16 TYP AT SIDES 1/4(1/8) TYP AT TOP/BTM NOTE: 1. AT FABRICATOR'S OPTION, MAY BE USED IN LIEU OF THIS DETAIL. 11/S536
