A kinked steel beam connects to a steel column featuring a cap plate sized per plan and schedule. The steel beams are sized per plan and connected using a bolted configuration and complete joint penetration welds at the top and bottom flanges. A metal roof deck spans across the top of the steel beams.
STEEL COLUMN AND CAP PLATE, SEE PLAN AND SCHEDULE STEEL BEAM, SEE PLAN AND STEEL TO STEEL CONNECTION SCHEDULE KINKED BEAM, SEE PLAN AND DETAIL ON SHEET SE5-14 STEEL BEAM, SEE PLAN AND STEEL TO STEEL CONNECTION SCHEDULE METAL ROOF DECK, SEE PLAN AND SCHEDULE CJP TOP AND BOTTOM CJP TYP 0' - 1 1/2" 0' - 1 1/2"
