A wide flange beam is positioned below reference elevations and aligned with a central grid line, supported by secondary structural members below. A five-sixteenth inch fillet weld connects the framing elements at the plate interface. The assembly includes a channel member, designated as an MC12 beam below, alongside adjacent structural steel components. A note clarifies that the slab edge is omitted for clarity. Dimensions of one and a half inches, four and a half inches, and three-quarters of an inch establish the vertical and horizontal clearances.
GRID 1 1/2" 4 1/2" 3/4" WF BEAM BELOW REF. ELEVATIONS 5/16 WF AND MC12 BEAM BELOW 5/16 SLAB EDGE NOT SHOWN FOR CLARITY SECTION A-A 7 S6.03
