Metal deck requires a minimum of one inch of bearing on the steel beam flange. Perform deck attachment in accordance with the project diaphragm attachment schedule. The erector must field-cut any high hat sections in the deck to ensure proper seating.
Text on the drawing
CUT HIGH HAT IN FIELD (BY ERECTOR) START NEW SHEET BEARING 1" MIN DECK ATTACHMENT RE: DIAPHRAGM ATTACHMENT SCHEDULE DECK ATTACHMENT RE: DIAPHRAGM ATTACHMENT SCHEDULE DECK ATTACHMENT RE: DIAPHRAGM ATTACHMENT SCHEDULE HAUNCH OVER BEAM 4" MINIMUM BEARING 1" MINIMUM
