An open web steel joist bears directly onto a steel column with a cap plate and welded connections. A three-eighths-inch by four-inch by one-foot-zero-inch required web stiffener is welded to the column web. The bottom chords of the joist are left unwelded to the stabilizer plate unless noted otherwise. Metal roof deck runs continuously across the top of the assembly.
NOTE: DO NOT WELD BOTT CHORDS TO STABILIZER PL (UNO) WEB STIFFENER STL JST, TYP GIRDERS AND BMS NOT SHOWN FOR CLARITY STIFFENER PL, TYP MTL ROOF DECK CAP PL WEB STIFFENER 3/8"x4"x1'-0" REQ'D 1/4 1/4 3 3 PL TO JST STL COL 2
