An electrical conduit is suspended from the overhead structure using a clevis hanger secured with a threaded rod at a maximum spacing of ten feet on center and at conduit bends. A Unistrut channel brace is installed at a maximum forty-five-degree angle to limit lateral movement, accommodating up to seventy-five pounds maximum load. A cross bolt sleeve secures the clevis hanger assembly around the conduit. The threaded rod connects to the overhead structure above per the structural drawings.
CLEVIS HANGER ELECTRICAL CONDUIT CROSS BOLT SLEEVE THREADED ROD@ 10'-0" MAX REFER TO 2/S-66111 FOR CONNECTION TO STRUCTURE ABOVE NOTE: PROVIDE CLEVIS HANGER AT 10'-0" OC MAX SPACING ALONG LENGTH OF CONDUIT AND AT BENDS IN CONDUIT. UNISTRUT ?? CHANNEL BRACE 45.00° MAX +/- 75 LBS MAX 2/ S-66111 SIDE VIEW UNISTRUT CHANNEL BRACE PIPE / ELECTRICAL CONDUIT 45.00° MAX +/- 75 LBS MAX
