A diagonal brace frames into the intersection of a wide flange column and wide flange beam at a designated work point. A three-eighths by four inch gusset plate connects the diagonal brace to the structural members. Five-sixteenths inch fillet welds secure the connection components, and the vertical legs of the angle below are trimmed as indicated.
4 3 TRIM VERTICAL LEGS OF ANGLE BELOW WORK POINT DIAGONAL BRACE REF. PLAN WF COL. REF. PLAN WF BEAM REF. PLAN PLAN VIEW 6 2" 5/16 5/16 3 5/16 3 PL3/8x4 C
