An angle brace connects between two structural steel beams positioned below a concrete-filled metal deck with reinforcing. The brace fastens at each end with two three-quarter-inch diameter bolts through three-eighth-inch by six-inch gusset plates welded to the beam webs with typical quarter-inch fillet welds.
BEAM PER PLAN ANGLE BRACE PER PLAN W/ (2) 3/4"Ø BOLTS EA END CONC OVER METAL DECK & REINF WHERE OCCURS BEAM PER PLAN 1/4 TYP PL3/8x6, TYP T/STL PER PLAN C L TYP 2 1/2" TYP 1 1/2" TYP 1 1/2" TYP 3"
