An HSS8x8x1/4 stub hanger connects structural members between an HSS beam sized per plan and a continuous vertical support. A roof deck bears on the framing with size and attachment specified in the structural schedule. Additional framing and connection angles tie into the assembly per detail references, positioned above a window assembly per architectural drawings.
SEE DETAIL 13/S231 ROOF DECK - SEE SCHEDULE FOR SIZE AND ATTACHMENT WINDOW - PER ARCH. HSS BEAM - SEE PLAN SEE DETAIL 13/S231 HSS8X8X1/4 STUB BETWEEN HANGER AND CONTINUOUS
