Sixteen millimeter thick stiffeners are welded to the web with fillet welds and to the flanges with full penetration butt welds. Flange connection plates are secured with bolts spaced forty-five millimeters on center. Electrode classification MEPS 70/35 is specified for the welding.
16mm stiffeners 8FWAR to web FPBW flanges PLAN VEIW 45 45 45 45 MEPS 70/35 MEPS 70/35
