An interior stepped continuous concrete footing supports a concrete pedestal and building column, adjacent to a fuel oil trench. The continuous footing reinforcement follows the continuous footing schedule with typical 'LST' and 'LSB' lap splices configured at the step transition. The step dimension is limited to a maximum of two feet six inches. Reinforcing bars match the foundation reinforcement requirements and are spaced equally across the step slope.
BUILDING COL. EDGE OF PEDESTAL AND FTG. STEP FUEL OIL TRENCH - SEE MECH. MATCH FDN. REINF. PEDESTAL - SEE 3/S5521 FTG. REINF. PER CONT. FTG. SCHED., TYP. 'LST' LAP, TYP. CONT. FTG. - SEE PLAN ALIGN WITH EDGE OF PEDESTAL 'LSB' LAP, TYP. 2'-6" MAX. MATCH STEP DIMENSION EQ. EQ. 2' - 6" MAX.
