A structural torsional connection with stiffeners applied to all four sides of a stairwell framing condition. The drawing specifies that no kickers are used, relying instead on the torsional connection systems labeled as TCS. Referencing typical torsional connections at stairwell A, the assembly coordinates the framing geometry without diagonal bracing kickers.
NO KICKER TYPICAL ALL FOUR SIDES TCS TCS TCS TCS TORSION CONNECTION WITH STIFFENER. SEE TYPICAL TORSIONAL CONNECTION AT STAIRWELL A NO KICKERS NO KICKER TYPICAL ALL FOUR SIDES TCS TCS TCS TCS TORSION CONNECTION WITH STIFFENER. SEE TYPICAL TORSIONAL CONNECTION AT STAIRWELL A NO KICKERS
