This plan view details the structural connection between a truss girder and a precast concrete wall panel. The assembly features three 3/8-inch gusset plates welded with 5/16-inch fillets to secure the truss girder alignment. The precast concrete wall panel incorporates internal reinforcement detailed per the panel elevation. Dimensions space the connection components relative to the centerline of the truss girder.
2" 2" PLAN VIEW (3) 3/8" GUSSET PL 4" C OF TRUSS GIRDER L 4" 8" 8" 17 - 5/16 PRECAST CONCRETE WALL PANEL REINFORCEMENT SEE PANEL ELEVATION 4"
