An eight-inch concrete masonry unit wall terminates near a structural column or wall, maintaining a gap filled with firestopping or waterproofing material per architectural drawings. The masonry wall is fully supported at the base, utilizing vertical reinforcement sized per the non-load-bearing wall schedule. Horizontal hooks match the size and spacing of horizontal reinforcement.
1/2" CMU WALL, FULLY SUPPORTED AT BASE END OF WALL GAP, FILL W/ FIRESTOP OR WATER PROOFING MATERIAL PER THE ARCH DWGS STRUC COL OR WALL VERT PER "CMU NON-LOAD BRG WALL REINF SCHED" 8" MASONRY WALL 29" Lcmu HOOKS TO MATCH SIZE & SPCG OF HORIZ REINF STRUC COL OR WALL
