A buckling-restrained braced frame wide flange column rests on a base plate atop a reinforced concrete footing, which sits on an approved subgrade designed to achieve specified bearing pressure. The column base assembly includes anchor rods extending into the footing, while separate soil tension anchors pass through the footing inside one-quarter-inch oversized PVC sleeves. Reinforcing steel is placed throughout the concrete footing with three-inch typical clearance to the exterior faces.
BRBF WF COL. REF. ELEVATIONS SLAB ON GRADE REF. PLAN 'T' WIDTH APPROVED SUBGRADE TO ACHIEVE BEARING PRESSURE LISTED IN THE GENERAL STRUCTURAL NOTES EXTEND TENSION ANCHOR BAR IN 1/4" OVERSIZED PVC SLEEVE THROUGH FOOTING BRBF WF. COL. BASE PL. AND ANCHORS REF. ELEVATIONS BEARING PL. (BY SOIL TENSION ANCHOR DESIGNER) SOIL TENSION ANCHOR REF. SCHED. AND NOTE 1 REINF. REF. SCHED. 3" CLR. NOTE: SOIL TENSION ANCHORS AS OCCURS REF. PLAN AND 4/S500 TYP. 3" CLR. 20 10
