An interior slab-on-grade construction joint occurs between a first pour and a second pour. Reinforcement continues across the construction joint because the slab functions as a structural diaphragm, meaning the fresh side of the joint must not be through-cut or trench saw-cut. A thirty-two inch lap splice is provided for the reinforcing steel, with two inches of clearance typically maintained. The interface requires the concrete to be cleaned, free of laitance, and intentionally roughened to a quarter-inch profile. The contractor must submit a slab-on-grade pour plan for engineer review prior to pouring, keeping the maximum pour dimension to two hundred feet with a two-to-one maximum aspect ratio.
CONTINUE REINFORCEMENT ACROSS CONSTRUCTION JOINT SLAB IS A STRUCTURAL DIAPHRAGM - DO NOT THROUGH CUT OR TRENCH SAW CUT FRESH SIDE OF JOINT SIMILAR TO CRACK CONTROL JOINT FIRST POUR SECOND POUR NOTE: CONTRACTOR TO SUBMIT S.O.G. POUR PLAN FOR ENGINEER'S REVIEW PRIOR TO POUR. MAX. DIMENSION OF S.O.G. POUR TO BE 200'-0" W/ 2:1 MAX. ASPECT RATIO. SLAB THICKNESS 2" CLR., TYP. CONCRETE SHALL BE CLEANED AND FREE OF LAITANCE. INTENTIONALLY ROUGHEN SURFACE TO 1/4" 32" LAP SPLICE S-5021 1" = 1'-0" 4 TYPICAL INTERIOR S.O.G. NON-STRUCTURAL CURB
