Level 2 bypass framing details a deflection track secured with two number twelve self-tapping metal screws at eight inches on center, or alternatively a one-inch weld top and bottom at eight inches on center, or two Hilti powder-actuated fasteners through a five-sixteenths-inch base plate at eight inches on center. The cold-formed steel framing utilizes a deflection track with two number twelve self-tapping metal screws connecting to the stud. Vertical stud framing is provided per schedule.
B LEVEL 2 327' - 2" TSN DTSLB800 W/ (2) #12 SMS TO STUD TSN DRIFTTRACK DT W/ (2) #12 SMS @ 8" OC OR 1" WELD TOP & BOTTOM @ 8" OC OR (2) HILTI X-U PAF THRU BPL @ 8" OC 5/16" BPL STUD FRAMING PER SCHEDULE
