Cold-formed metal framing wall studs interface with the edge of a composite concrete slab supported by a structural steel wide-flange beam. A vertical slip connection resists lateral loads only and is designed by the cold-formed metal framing supplier. An eight-inch kicker brace and connection tie the framing back to the beam, with the top kicker connection located eight inches back from the slab edge. Additional information is referenced on sheet 10/S-553, and composite slab reinforcement is omitted for clarity.
CL WF BEAM SEE PLAN FOR DECK ORIENTATION COMPOSITE SLAB SEE PLAN WF BEAM SEE PLAN T/SLAB SEE PLAN T/STEEL SEE PLAN SEE PLAN CFMF WALL STUD SEE ARCH VERTICAL SLIP CONN TO RESIST LATERAL LOADS ONLY DESIGNED BY CFMF SUPPLIER FOR ADDITIONAL INFO SEE 10/S-553 CFMF WALL STUD SEE ARCH 8" KICKER AND CONNECTION AS REQD PER 10/S-553 LOCATE TOP KICKER CONN 8" BACK FROM SLAB EDGE NOTE: COMPOSITE SLAB REINF NOT SHOWN FOR CLARITY
