Concrete is cast over a metal floor deck bearing on a wide-flange steel beam. The steel beam connects to the wide-flange steel column using bolted shear tabs. Additional stud framing is provided by the supplier as needed, with gravity connections using screws or welds to attach the studs to the structure. Architectural finishes are applied per architectural drawings.
A A CONC OVER MTL FLR DECK STL BM WF COL STL BM SEE DETAILS AND FOR INFO NOT NOTED / (1 S611) 1 S602 1 S802 S602 3 / (6 S610) FINISHES, SEE ARCH GRAVITY CONNECTION (SCREWS OR WELD) OF STUDS TO STRUCT BY SUPPLIER STUD FRAMING AS NEEDED, BY SUPPLIER MTL DECK
