A haunch plate is welded to the steel beam web with a slotted plate detail around the web for the haunch plate length. Shear studs are specified at a minimum of two studs per foot. The connection utilizes fillet welds on both sides of the plate and is referenced to grid lines or centerlines of support. Section A shows the transverse profile of the haunch plate and beam flange dimensions.
A 1 LENGTH, SEE PLAN GRID OR CL OF SUPPORT 18 7/8" D SEE PLAN FOR LOC 23 1/2" (2) STUDS/ FT MIN SLOT PL AROUND WEB FOR HAUNCH PL LENGTH 13 1/4" DEPTH ES WELD WELD TYPE 1 ELEVATION MARK 12" WIDTH WELD WELD HAUNCH PL SECTION A GRID OR CL OF SUPPORT SEE PLAN FOR LOC DEPTH 13 1/4" LENGTH, SEE PLAN 4
