A metal deck bears on a wide flange steel beam with a one and a half inch minimum end bearing distance. A sixteen gauge closure angle is puddle welded to the beam following the deck welding schedule. A continuous number four reinforcing bar runs along the slab edge, which aligns with the edge of the beam flange as indicated on the architectural drawings.
16 GA CLOSURE - PW TO BEAM PER DECK WELDING SCHEDULE METAL DECK (DIRECTION OF DECK MAY VARY) TYP REINF WF BEAM MIN 1 1/2" CL WHS END OF MTL DECK #4 CONT EDGE OF SLAB TO MATCH EDGE OF FLANGE WHERE INDICATED ON ARCH DWG
