This connection fastens a cross-laminated timber panel to the top chord of a glulam timber truss. SDWS22 structural wood screws are spaced at one foot six inches on center, centered on the glulam truss members and installed either perpendicular or vertically at the contractor's option. The screws provide a minimum two and one-half inch embedment into the glulam truss chord member.
NOTES: 1. AT CONTRACTORS OPTION, SCREW MAY BE INSTALLED VERTICAL IN LIEU OF PERPENDICULAR TO PANEL. SDWS22@1'-6" O.C, CTR ON GLULAM TRUSS MEMBERS, TYP. PROVIDE MIN 2 1/2" EMBED INTO GLULAM TRUSS CHORD MEMBER. SEE NOTE 1. CLT PANEL GLULAM TRUSS TOP CHORD 10 TYPICAL CLT PANEL TO TRUSS CONN
