Steel roof joists support a metal roof deck across a structural grid line with an expansion joint. X-type bridging is provided by the joist supplier and secured with three-sixteenths inch fillet welds typical for plate and deck connections. Expansion joint dimensions and joist design upgrades are referenced to another drawing detail. A structural grid line is centered at the expansion joint gap between the framing bays.
STL JST 'X' BRDG BY JST SUPPLIER MTL ROOF DECK GRID MTL ROOF DECK STL JST 3/16 TYP FOR PL AND DECK CONN AND JST DESIGN UPGRADES, SEE DET / (4 S7.3) FOR EXPANSION JOINT DIMS, SEE DET / (4 S7.3)
