This plan detail shows a concrete panel corner reinforced with number five vertical bars at nine inches on center each face and two number five vertical bars full height. The eight-inch thick wall section includes corner ties sized and spaced to match detail 7 on sheet SD3. Typical pier reinforcement and panel return dimensions are coordinated with the panel elevations.
