This structural framing plan details a hinged grating assembly supported by structural steel beams sized per plan. The metal grating spans between parallel beams and requires a minimum three-inch bearing at each support. A hinged access section is integrated into the grating layout, with overall dimensions and span lengths sized per plan.
FRAMING PLAN HINGED GRATING, SEE PLAN GRATING SPAN SEE PLAN MIN 3' - 0" BEARING 3" MIN BEARING 3" MIN GRATING, SEE PLAN BEAM, SEE PLAN BEAM, SEE PLAN
