A two-inch concrete tread is placed within a typical twelve gauge metal pan, with geometry determined per architectural drawings. The metal pan connects to the stair stringer via a one-eighth-inch fillet weld spaced at six inches for the pan-to-stringer connection, and four to twelve inches for the tread-to-tread connection. A guard rail post is anchored directly to the assembly per architectural requirements, and tread dimensions are coordinated with architectural drawings.
2" CONC TREAD, TYP 12 GA MATAL PAN, TYP. GEOMETRY PER ARCH STRINGER PER PLAN 1/8 4-12 TREAD TO TREAD 1/8 6 PAN TO STRINGER NOTES: 1. SEE ARCHITECTURAL DRAWINGS FOR TREAD DIMENSIONS. GUARD RAIL POST PER ARCH
