An edge angle is positioned to receive curtain wall attachments, with the vertical leg notched at attachment locations per coordination with the curtain wall manufacturer.
EDGE ANGLE PER & CURTAIN WALL ATTACHMENT, NOTE 1 NOTCH ANGLE VERT LEG @ CURTAIN WALL ATTACHMENT LOCATIONS, NOTE 1 NOTES: 1. CONTRACTOR TO COORDINATE CURTAIN WALL ATTACHMENT LOCATIONS W/ CURTAIN WALL MFR.
