An HSS rail support post welds to a three-eighths-inch by five-inch by one-foot-six-inch embedded steel plate with a one-quarter-inch fillet weld. The embedded plate secures to the concrete elevator pit wall using three seven-eighths-inch diameter by four-inch headed studs spaced at five inches on center typical.
EMBEDDED PL 3/8x5x1'-6" w/ (3) 7/8"Ø x 4" HEADED STUDS @ 5" o.c. TYP. HSS RAIL SUPPORT POST REF. PLAN ELEVATOR PIT WALL REF. 10/S511 1/4
