An angle measuring 3 1/2 inches by 2 1/2 inches by 1/4 inch and 0 feet 9 inches long is secured to the stair stringer with two 5/8-inch diameter by 2-inch lag screws. The angle supports the glass tread and deck topping as specified per the architectural plan. A maximum shim gap of 1/8 inch is detailed with rigid material between components. A guardrail plate per architectural drawings aligns adjacent to the stringer, featuring a 3/16-inch weld symbol.
GUARDRAIL PL PER ARCH'L 3/16 L 3 1/2 x 2 1/2 x 1/4 x 0'-9" (LLH) W/ (2) 5/8" ⌀ x2" LAG SCREWS GL TREAD PER PLAN (DECK & TOPPING WHERE OCCURS PER PLAN) 1 1/4" 1/8" MAX. SHIM GAP W/ RIGID MATERIAL STRINGER PER PLAN 6 E
