A non-frame pipe column or hollow structural section tube bears on a base plate atop a concrete footing or pilaster. The base plate is secured with anchor bolts featuring double nuts and hardened washers, bearing on half-inch by four-inch square plate washers typically embedded at the footing depth. A three-inch minimum non-shrink grout layer is provided beneath the base plate. The concrete footing is reinforced with number four ties spaced at six inches on center with a minimum of three ties at the footing.
NON-FRAME PIPE COLUMN (HSS TUBE SIM) BOT OF BASE PL - SEE SCHEDULE TOP OF FOOTING/PILASTER AB'S - SEE SCHEDULE W/ DOUBLE NUTS AND HARDENED WASHERS ELEVATION BOTTOM OF FOOTING - SEE FOOTING SCHEDULE 1/2"x4" SQ PL WASHER, TYP #4 TIES @ 6" (3 TIES MIN) AT FOOTING. TYP 3" MIN GROUT 3" NON-SHRINK SEE SCHED BASE PL FOOTING DEPTH SEE SCHEDULE
