Footings shall bear on engineered structural fill extending down to native soils with a minimum lateral extent equal to half the fill depth. Refer to earthwork notes and soils report for additional information.
H/2 MIN. FOOTINGS SHALL BEAR ON ENGINEERED STRUCTURAL FILL EXTENDING DOWN TO NATIVE SOILS. H SEE EARTHWORK NOTES AND SOILS REPORT FOR ADDITIONAL INFORMATION.
