An eight-inch concrete masonry unit wall terminates adjacent to a structural column or wall with a half-inch end gap filled with firestop or waterproofing material per architectural drawings. Vertical reinforcement is placed per the non-load bearing concrete masonry unit wall reinforcing schedule, while horizontal reinforcement hooks match the size and spacing of horizontal reinforcing bars. The end of the wall requires an Lcmu length dimension with fully supported base conditions. A note restricts this detail from being applied where wall openings are within two feet eight inches of the wall end.
1/2" CMU WALL, FULLY SUPPORTED AT BASE END OF WALL GAP, FILL W/ FIRESTOP OR WATER PROOFING MATERIAL PER THE ARCH DWGS STRUC COL OR WALL VERT PER "CMU NON-LOAD BRG WALL REINF SCHED" 8" MASONRY WALL 29" Lcmu HOOKS TO MATCH SIZE & SPCG OF HORIZ REINF NOTES: 1. DETAIL IS NOT APPLICABLE WHERE OPENINGS ARE WITHIN 2'-8" OF THE END OF WALL. CONTRACTOR SHALL SUBMIT CONDITIONS WITH OPENINGS FOR ENGINEER TO REVIEW. E TYPICAL NON-LOAD BEARING CMU WALL
