This drawing outlines the mounting height requirements for thermostats, switches, and outlet controls relative to the finished floor. For unobstructed side approach, the maximum height to the centerline is forty-eight inches, while side reach over an obstruction allows a maximum height of forty-six inches. Front approach allows a maximum height of forty-four inches to the top of the device with a maximum obstruction depth of twenty-four inches.
48" MAX 46" MAX-SIDE APPROACH 24" MAX 34" MAX 44" MAX FRONT APPROACH FINISHED FLOOR CENTERLINE OF THERMOSTAT SWITCH, OUTLET CONTROL FINISHED FLOOR TOP OF THERMOSTAT SWITCH, OUTLET CONTROL
