This structural detail shows the connection and splicing of channel chord ties across steel joists with continuous bottom plates and three-eighths-inch by three-inch by one-foot-six-inch splice and strap plates centered over the joints. Fillet welds join the plates to the structural members as specified. Additional details illustrate alternate splices with one-foot-six-inch overlaps, ridge and valley configurations with bent plates, and intermediate conditions between joists.
CONT BOTT PL AS SHOWN ON PLAN CHANNEL CHORD TIE AS SHOWN ON PLAN STRAP PL 3/8"x3"x1'-6" CTRD OVER SPLICE BEND AS REQD CHANNEL CHORD, TIE AS SHOWN ON PLAN BEND BOTT PL OVER OVER JST AT RIDGE AT VALLEY SPLICE PL 3/8"x3"x1'-6" STRAP PL 3/8"x3"x1'-6" CTRD OVER SPLICE BTWN JSTS STL JST STL JST 1/4 TYP 1/8 1/8 3/16 3-12 3/4 6 TYP 1'-6" OVERLAP ALTERNATE SPLICE CONT BOTT PL PER PLAN CHANNEL PER PLAN 1/4 1/4 TYP PL TO JST, TYP T-720-06
