A buckling-restrained brace passes through a concrete-filled steel deck floor assembly at the building edge. A bent plate coordinates the horizontal leg with a minimum deck bearing length for field alignment. An edge plate extends beyond the wide-flange beam per plan. Edge closure details seal the slab termination at the grid line.
11" 4" MIN TYP CONC ON STL DECK EDGE PL3/8x5 1/4 BEYOND WF BM PER PLAN BRB 3" APPROX 3" TO 4" TYP, ES BENT PL3/8 COORD HORIZ LEG W/ MIN DECK BRG LENGTH, FIELD ALIGN, TYP 3 3/16 AT EA BM, TYP 3 3/16 14 S6.01 WF BM BEYOND GRID BRB EDGE CLOSURE PER TYP DET VARIES TOC
