A reinforced concrete column to beam joint features designated construction joints and specific concrete mix puddling zones. Where the column concrete compressive strength exceeds 1.25 times the beam concrete compressive strength, higher strength concrete is puddeled within the hatched area extending typically two feet from the column face. At spirally reinforced columns, the beam must be puddled with a concrete compressive strength equal to that of the column. Similar strength differential requirements apply between the column and slab concrete within the junction zone.
COLUMN TO BEAM JOINT NOTES: 1. WHERE THE COLUMN CONCRETE f'c EXCEEDS 1.25 TIMES THE BEAM CONCRETE f'c, PUDDLE CONCRETE WITH f'c EQUAL OR GREATER THAN THE COLUMN CONCRETE f'c WITHIN THE HATCHED AREA. AT SPIRALLY REINFORCED COLUMNS, BEAM SHALL BE PUDDLED WITH f'c EQUAL TO COLUMN f'c. 2. WHERE THE COLUMN CONCRETE f'c IS GREATER THAN 1.4 TIMES THE SLAB CONCRETE f'c, PUDDLE CONCRETE WITH f'c EQUAL TO OR GREATER THAN THE COLUMN CONCRETE f'c WITHIN THE HATCHED AREA. CJ CONC COL CJ TYP 2' - 0" NOTE 1 CONC BM REINF PER CONC BM SCHED
