A wide-flange column and buckling-restrained brace connect to a grade 50 base plate anchored atop a reinforced concrete footing. A 1 1/2-inch non-shrink grout layer sits beneath the base plate with a 1 1/2-inch anchor bolt projection. The buckling-restrained brace connects via a gusset plate and connection detailed per the manufacturer. The concrete footing includes an anchor plate measuring 1 3/4 by 12 inches by 1 foot 7 inches in grade 50 steel, reinforced with number 4 ties at 4 inches on center.
T/FTG B/FTG EL PER PLAN WF COLUMN PER ELEV CL COLUMN GROUT 1 1/2" NON-SHRINK 5" 1" CONC FOOTING PER PLAN ANCHOR PL 1 3/4x12x1'-7", GR 50 PROJECTION 1 1/2" #4 TIES @ 4" OC CL BRB BRB GUSSET PL, GUSSET CONN AND BRB CONN PER BRB MFR BASE PL 2, GRADE 50 CONC FOOTING PER PLAN 1 1 MIN 6" MIN 6" 1'-2" 8 S-521 ____ WP
