Two shear studs per flute are welded through the B-type metal deck along the center line of the supporting steel beam. The supporting beam flange requires a four-inch minimum width to accommodate the dual stud arrangement.
AT B-TYPE DECK TWO STUDS PER FLUTE (4" MIN. BEAM FLANGE) CL BEAM
