A two-hour fire-rated elevator entrance frame assembly connects the corridor to the elevator shaft using a steel elevator door jamb and a steel J-runner. A stainless steel elevator door is positioned at the opening, with clear opening dimensions sized per plan. The framing includes a two-inch clearance detail at the corridor transition, supplied and installed by the elevator manufacturer.
ELEVATOR SHAFT STEEL J-RUNNER STAINLESS STEEL ELEVATOR DOOR . CLEAR OPENING SEE PLANS NOTE: 2" CORRIDOR 2 HOUR FIRE RATED ENTRANCE FRAME ASSEMBLY WITH STEEL ELEVATOR DOOR JAMB, BY ELEV. MFR.
