A built-up slab at the loading dock is supported by a metal deck bearing on a steel beam adjacent to a reinforced basement wall. The concrete slab incorporates a polystyrene insulation layer and is reinforced per structural drawings. A deck support angle is anchored to the basement wall per typical details.
4 LEVEL 1 BSMT WALL, REINF PER ELS BU SLAB AT LOADING DOCK PER "TYPICAL BUILT-UP SLAB ON POLYSTYRENE" DET DECK SUPT ANGLE PER TYP DETS
