A structural steel column terminates at a base plate secured with anchor bolts anchored into a concrete foundation wall and grade beam. The column base plate connection detail is specified per plan. The embedded steel column aligns with the centerline of the concrete column below, adjacent to a concrete slab extending beyond.
TYPICAL STEEL COLUMN BASE AT CONTINUOUS FOUNDATION WALL * OF COL. STL COL. COL. BASE / CONN. PER SLAB BEYOND CONC. BM PER PLAN CONC. COL. CONC. BM PER PLAN 1 S34-03 * OF COL. CONC. WALL PER EL./ PLAN CONC. BM PER PLAN STL COL. EMBEDED COL. BASE / CONN. PER CONC. BM PER PLAN CONC. SLAB BEYOND CONC. COL. 1 S34-03 1" = 1'-0" S34-03 3 SECTION
