This structural detail shows a five-eighths inch plate connecting a reduced column section below. Fourteen fasteners are arranged symmetrically across the plate with specified edge distances and spacing dimensions of one and one-quarter inches, one and three-quarters inches, and one and seven-eighths inches.
SECTION B-B PL 5/8" REDUCED COL. SECTION BELOW (14) SDCP27614 1 3/4" 1 7/8" TYP. 1 1/4" EQ. EQ.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
