A concrete slab on metal deck bears on a structural steel edge beam and framing beam, supported by a continuous 12-gauge metal edge form. Reinforcing includes continuous bars at the edge and number 3 bars spaced at 12 inches on center. A puddle weld connects the metal deck to the supporting beam flange. An L5x5x3/8 angle is placed at a maximum 10-foot spacing as sized per plan and aligned with the beam on the opposite side.
(2'-7" MAX) D 6'-0" 2#4 CONT L5x5x3/8 UNO ON PLAN @ 10'-0" MAX (ALIGN W/ BEAM AT OPPOSITE SIDE) 12 GA CONT EDGE FORM EDGE BEAM SEE PLAN BEAM SEE PLAN #3@12" OC (2'-7" MAX) SEE PLAN 3/8 PP 1/2" TYP 1/4 2 SIDES 2" MIN
