Steel Column and Tilt-Up Panel Foundation Connection

Materials

Concrete Steel Masonry / CMU

Elements

Columns Beams Floors / Slabs Foundations / Footings Arches Connections / Plates Reinforcing

Connections

Rebar Splice / Development

About this detail

A steel column bears on a concrete foundation system featuring a concrete footing, a concrete grade beam, and a concrete slab on grade with a pour-back strip. A two-inch non-shrink grout layer is positioned beneath the column baseplate on top of the footing. A concrete tilt-up panel intersects the assembly with a reveal, while a twenty-four-inch by twenty-four-inch block-out in the slab is poured solid after the column is installed. Reinforcing bars run through the block-out with hooked bars where the column intersects long bars, and gravel bed material sits above the grade beam.
