A pipe sleeve penetrates a metal roof deck, framed by structural steel angles welded to supporting steel beams with three-sixteenths inch typical fillet welds. Openings are reinforced using angle frames such as L5x3x1/4 or L3x3x1/4 with optional construction details for trimming the vertical leg at joists. An eighteen gauge plate is fastened over the assembly at the roof deck using number ten sheet metal screws at six inches on center each way. Sizing criteria dictates opening dimensions corresponding to pipe diameters up to thirty-six inches square for pipes under twelve inches in diameter, down to twelve inches square for pipes four inches or less in diameter.
OPENING SEE ARCH/MECH OPTION B NOTES: 1. SEE DETAIL 3/S521 FOR OPENINGS LESS THAN 12" IN DIAMETER. 2. 3. SEE TYPICAL ROOF TOP MECHANICAL UNIT SUPPORT DETAIL(S) FOR FRAMES UNDER MECHANICAL UNITS. ROOF DECK TO BE WELDED TO ANGLE FRAMING. TRIM VERTICAL LEG AT JOIST STEEL BEAM, SEE PLANS L5x3x1/4 (LLV) x 0'-6" TYP. CONTRACTOR MAY USE OPTION B IF DESIRED ANGLE FRAME L5x3x1/4 (LLV) 3/16 TYP TYP 3/16 3/16 3/16 TYP 3/16 A A SECTION A-A OPEN OPEN OPEN OPEN TRIM VERTICAL LEG AT JOIST 3/16 TYP 3/16 STEEL BEAM, SEE PLANS A A A A 3/16 TYP 3/16 TYP TYP 3/16 3/16 TYP 3/16 3/16 ANGLE FRAME L3x3x1/4, TYP ANGLE FRAME L3x3x1/4, TYP L3x3x1/4 x 0'-6" TYP. CONTRACTOR MAY USE OPTION B IF DESIRED L3x3x1/4 x 0'-6" TYP. CONTRACTOR MAY USE OPTION B IF DESIRED OPTION B SECTION A-A PIPE SLEEVE 18 GA PLATE WITH #10 SHEET METAL SCREWS AT 6" O.C. EACH WAY METAL ROOF DECK PLAN VIEW 36" SQ. < 12"DIA 24" SQ. ≤ 8"DIA 12" SQ. ≤ 4"DIA A 1 2 3
