Six-inch cold-formed steel studs are spaced at sixteen inches on center typically, set adjacent to a roof assembly with an eight-inch expansion joint. A continuous galvanized two-by-two-by-quarter-inch angle connects to the galvanized beam sized per plan with a quarter-inch fillet weld. The roof deck is installed per plan bearing on the structural framing.
12 11.9 6" CFS STUDS @ 16" OC, TYP GALV BM PER PLAN 1' - 2" 1' - 0" 1/4 2-12 GALV L2X2X1/4 CONT 1' - 0" RF DK PER PLAN EJ 8" 3 2 4
