An interior metal stud wall bears on an eight-inch concrete slab on grade, separated from an adjacent eight-inch reinforced concrete slab on grade by a compressible bond breaker. The slabs occur on both sides of the joint under similar conditions.
COMPRESSIBLE BOND BREAKER BETWEEN SLABS 8" CONC. SLAB ON GRADE REINFORCED PER PLAN INTERIOR SLAB ON GRADE INTERIOR METAL STUD WALL - SEE ARCH. @ SIM. CONDITION, 8" REINFORCED SLAB OCCURS ON BOTH SIDES OF JOINT
